  1. Solar Cell Directory
  2. LWM10BB-PERC-182
LWM10BB-PERC-182

LWM10BB-PERC-182

Lightway Solar Energy Technology Ltd
Price:
From €0.0094 / Wp
Cell Type: PERC
Power Range: 7.2~7.49 Wp
Region: China China
Contact Manufacturer
Note: Your Enquiry will be sent directly to Lightway Solar Energy Technology Ltd.

Alternative Product

AL-M2M156.75-5BB

Aoli Solar
From €0.0714 / Wp
  • Maximum Power: 5.23 W
  • Cell Type: Monocrystalline
  • Dimensions: 156.75×156.75 mm
  • DIAGONAL: --
  • Cell Thickness: 170 µm
More

Product Characteristics

Model No.
LWM10BB-PERC-7.20W LWM10BB-PERC-7.23W LWM10BB-PERC-7.26W LWM10BB-PERC-7.30W LWM10BB-PERC-7.33W LWM10BB-PERC-7.36W LWM10BB-PERC-7.40W LWM10BB-PERC-7.43W LWM10BB-PERC-7.46W LWM10BB-PERC-7.49W
Product Characteristics
Cell Technology PERC
Dimensions 182x182 mm
Diagonal 247±0.5 mm
Cell Thickness 175 ± 20 µm
Front Surface (-)
No. of Busbars 10
Busbar Width 1.0 mm
Busbar Material Silver
Anti Reflection Coating Silicon nitride
Back Surface (+)
No. of Soldering Pads 10
Soldering Pad Width 2.1 mm
Soldering Pad Material Silver
Back Surface Field (BSF) Aluminium
Electrical Data at STC
Maximum Power (Pmax)
7.2 W 7.23 W 7.26 W 7.3 W 7.33 W 7.36 W 7.4 W 7.43 W 7.46 W 7.49 W
Voltage at Maximum Power Point (Vmpp)
0.584 V 0.585 V 0.586 V 0.587 V 0.588 V 0.589 V 0.59 V 0.591 V 0.592 V 0.593 V
Current at Maximum Power Point (Impp)
12.325 A 12.36 A 12.395 A 12.43 A 12.465 A 12.5 A 12.535 A 12.57 A 12.605 A 12.64 A
Open Circuit Voltage (Voc)
0.68 V 0.681 V 0.682 V 0.683 V 0.684 V 0.685 V 0.686 V 0.687 V 0.688 V 0.689 V
Short Circuit Current (Isc)
12.908 A 12.948 A 12.988 A 13.028 A 13.068 A 13.108 A 13.148 A 13.188 A 13.226 A 13.267 A
Fill Factor (FF)
82 % 82 % 82 % 82 % 82 % 82 % 82 % 81.99 % 82.01 % 82 %
Thermal Ratings
Temperature Coefficient of Pmax -0.39 %/˚C
Temperature Coefficient of Voc -0.3 %/˚C
Temperature Coefficient of Isc 0.06 %/˚C

Lightway Solar Energy Technology Ltd

Click to show company phone
www.lightway-solar.com
China
Xicheng Industrial Park, Baotian Rd., Xixiang Town, Bao'an District, Shenzhen, Guangdong
No. Staff: 550
Parent Company: Lightway Energy Technology Co., Limited
Contact Manufacturer
Note: Your Enquiry will be sent directly to Lightway Solar Energy Technology Ltd.

Useful Contacts

Contact Face
Sales Dept Sales Dept
Contact Face
Anna Lee Overseas Sales
Contact Face
Lizzy Leung Overseas Sales
Contact Face
Zoe Zhang Overseas Sales
Contact Face
David Zhu Sales Director
Contact Face
Administration Dept Administration Dept
Company Description

Lightway Solar was established in 2006,set up four companies in China mainland and owns two operating/sales companies in HongKong,with manufacturing factilities in Jiangsu/Jiangxi/Guangdong for solar cells/modules etc and global marketing/sales company in Shenzhen,our current annual production capacity is over 1.3GW for solar cell and solar module etc manufactured in CE/ISO/IEC/TUV/UL etc certificates.Lightway Solar devoted to offering clients a one-stop shop for high quality products and already recognized by many of our clients from all over the world up to 80 countries.
