Three Phase Grid-connected SI-4-12K-T2
Three Phase Grid-connected SI-4-12K-T2
Three Phase Grid-connected SI-4-12K-T2

Three Phase Grid-connected SI-4-12K-T2

Inhenergy Co., Ltd.
Type: On-Grid
Power Range: 4.4~13.2 kW
Region: China China
Note: Your Enquiry will be sent directly to Inhenergy Co., Ltd..

Alternative Product

Tiger Series 4...

Tentek
  • Type: Micro-inverter
  • Product Warranty: --
  • Protection Class: IP67
  • Dimension: 300x270x45 mm
  • Weight: 6.3 kg
More

Product Characteristics

Model No.
SI-4K-T2 SI-5K-T2 SI-6K-T2 SI-8K-T2 SI-10K-T2 SI-12K-T2
Warranty
Product Warranty (Min)
5 Years 5 Years 5 Years 5 Years 5 Years 5 Years
Input Data(DC)
Max. DC Power
5.2 kW 6.5 kW 7.8 kW 10.4 kW 13 kW 15.6 kW
Max. DC Voltage
1100 V 1100 V 1100 V 1100 V 1100 V 1100 V
Nominal DC Voltage
580 V 580 V 580 V 580 V 580 V 580 V
Rated DC Voltage
580 V 580 V 580 V 580 V 580 V 580 V
Min. DC Voltage to Start Feed In
200 V 200 V 200 V 200 V 200 V 200 V
Max. DC Current
28 A 28 A 28 A 28 A 28 A 28 A
Rated DC Current
14 A 14 A 14 A 14 A 14 A 14 A
MPP(T) Voltage Range
200~1000 V 200~1000 V 200~1000 V 200~1000 V 200~1000 V 200~1000 V
No of MPP Trackers
2 2 2 2 2 2
DC Inputs
2 2 2 2 2 2
Connectors
MC4 MC4 MC4 MC4 MC4 MC4
Output Data (AC)
Max. AC Power
4.4 kW 5.5 kW 6.6 kW 8.8 kW 11 kW 13.2 kW
Nominal AC Power
4 kW 5 kW 6 kW 8 kW 10 kW 12 kW
Output AC Voltage Range
320~480 V 320~480 V 320~480 V 320~480 V 320~480 V 320~480 V
Nominal AC Voltage
380, 400 V 380, 400 V 380, 400 V 380, 400 V 380, 400 V 380, 400 V
Rated AC Voltage
380 V 380 V 380 V 380 V 380 V 380 V
Max. AC Current
6.5 A 8 A 10 A 13 A 16 A 19 A
Rated AC Current
5.7 A 7.2 A 8.7 A 11.6 A 14.5 A 17.5 A
Frequency Range
45-65 Hz 45-65 Hz 45-65 Hz 45-60 Hz 45-65 Hz 45-65 Hz
Frequency
50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz
Power Factor (cosθ)
0.8 0.8 0.8 0.8 0.8 0.8
Distortion (THD)
< 3 % < 3 % < 3 % < 3 % < 3 % < 3 %
No of feed-in phases
3 3 3
Max. Efficiency
98.2 % 98.2 % 98.2 % 98.2 % 98.2 % 98.2 %
Euro Efficiency
98 % 98 % 98 % 98 % 98 % 98 %
General Data
Dimensions (H/W/D)
403x360x192 mm 403x360x192 mm 403x360x192 mm 403x360x192 mm 403x360x192 mm 403x360x192 mm
Weight
15 kg 15 kg 15 kg 15 kg 15 kg 15 kg
Power Consumption at Night
< 1 W < 1 W < 1 W < 1 W < 1 W < 1 W
Noise Level
< 30 dB(A) < 30 dB(A) < 30 dB(A) < 30 dB(A) < 30 dB(A) < 30 dB(A)
Operating Temperature -25 ~ +60 ℃
Transformer Transformerless
Protection Class IP65
Humidity 0-100 %
Cooling Natural
Max. Altitude 4000 m
Interface RS 232, RS 485, WLAN
Display LCD, LED
Protection Features
Protection Features Anti Island Protection(ENS), Short Circuit Protection, Overload Protection, Overvoltage Protection, Overcurrent Protection, Overtemperature Protection, Residual Current Device (RCD), Reverse Polarity Protection, Surge Protection, DC Load Disconnector, Ground Fault Monitoring, Isolation Monitoring, Grid Monitoring
PDF
Download Manufacturer's PDF

Inhenergy Co., Ltd.

Click to show company phone
www.inhenergy.com
China
INHE Smart Distribution Park, JinYuan 2nd, TangJiaWan Town, Xiangzhou, Zhuhai, Guangdong
Note: Your Enquiry will be sent directly to Inhenergy Co., Ltd..

Useful Contacts

Contact Face
Beatrice Sales
Contact Face
Sophie Sales
Contact Face
Tom Sales
Contact Face
Myra Sales
Company Description

INHENERGY Co., Ltd. is a high-tech enterprise specialized in solar inverter products and systems. Our skilled, experienced, and highly trained team is here to cover all of your needs related with solar inverters. Bearing in the mind the mission of "Power the World with Sunlight", INHENERGY continues research on key technologies, including photovoltaic grid-connected solution, solar storage and charging solution, demand side management, electricity transaction platform and micro-grid energy management system to improve the capability of intelligent scheduling, real-time transaction, field absorption and energy efficiency.
