WVC - 1200

WVC - 1200

Topraysol Group Co., Ltd.
Type: Micro-inverter
Power Range: 1.2 kW
Region: China China
Note: Your Enquiry will be sent directly to Topraysol Group Co., Ltd..

Alternative Product

  • Type: Micro-inverter
  • Product Warranty: 25 Years
  • Protection Class: IP67,NEMA 6
  • Dimension: 153x178x28 mm
  • Weight: 1.98 kg
  • Max. DC Power: 0.31 kW
  • Max. DC Voltage: 60 V
  • Max. DC Current: 10.5 A
  • MPP(T) Voltage Range: 27~48 V
  • No of MPP Trackers: --
  • Max. AC Power: 0.25 kW
  • Frequency: 60 Hz
  • Max. Efficiency: 96.7 %
  • Euro Efficiency: --
  • Feed-in Phases: --

Product Characteristics

Model No.
WVC - 1200 (120VAC) WVC - 1200 (230VAC)
Input Data(DC)
Max. DC Power
1.2 kW 1.2 kW
Max. DC Voltage
50 V 50 V
Min. DC Voltage to Start Feed In
22 V 22 V
Max. DC Current
54.4 A 54.4 A
Output Data (AC)
Max. AC Power
1.2 kW 1.2 kW
Output AC Voltage Range
80~160 V 180~260 V
Rated AC Voltage
120 V 230 V
Max. AC Current
9.58 A 5 A
Frequency Range
57-62.5 Hz 47-52.5 Hz
Frequency
60 Hz 50 Hz
Power Factor (cosθ)
0.98 0.98
Distortion (THD)
< 5 % < 5 %
No of feed-in phases
1 1
Max. Efficiency
90 % 90 %
General Data
Dimensions (H/W/D)
305x370x38 mm 305x370x38 mm
Weight
2.85 kg 2.85 kg
Power Consumption at Night
< 0.05 W < 0.07 W
Operating Temperature -40 ~ +82 ℃
Transformer Yes
Protection Class IP65
Cooling Natural
Interface RS 232, WLAN
