RL290-310HP-120

Name: RL290-310HP-120
Brand: Rarlon PV Tech
SKU: 44940
Price: 0.20000 USD
Availability: InStock

Ningbo Rarlon Photovoltaic Technology Co., Ltd.

Price:

From €0.173 / Wp

Technology:	--
Power Range:	290 ~ 310 Wp
Region:	China

Contact Manufacturer

Note: Your Enquiry will be sent directly to Ningbo Rarlon Photovoltaic Technology Co., Ltd..

Description:

Using MBB higher efficiency 158.75mm Mono cell and half cell technology. Power can be 390w-420w. By cutting solar cell into halves, the internal power loss will be lower and hot spot effect will also be reduced. This design effectively deals with the mismatch happened between cells caused by shadow, out of sync performance degradation, etc.

Product Info
Company Profile

Product Characteristics

Type

Polycrystalline

Model No.

RL290HP-120

RL295HP-120

RL300HP-120

RL305HP-120

RL310HP-120

Electrical Data at STC

Maximum Power (Pmax)

290 Wp

295 Wp

300 Wp

305 Wp

310 Wp

Voltage at Maximum Power (Vmpp)

32.78 V

33.23 V

31.52 V

31.88 V

32.3 V

Current at Maximum Power (Impp)

8.85 A

8.88 A

9.52 A

9.57 A

9.6 A

Open Circuit Voltage (Voc)

39 V

39.2 V

38.68 V

38.95 V

39.27 V

Short Circuit Current (Isc)

9.67 A

9.78 A

10 A

10.03 A

10.06 A

Panel Efficiency

17.45 %

17.75 %

18.05 %

18.36 %

18.66 %

Power Tolerance (Positive)

+ 3 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Temperature

45±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

-40~85 °C

Temperature Coefficient of Pmax

-0.39 %/°C

Temperature Coefficient of Voc

-0.29 %/°C

Temperature Coefficient of Isc

0.05 %/°C

Maximum Ratings

Maximum System Voltage

1000 V

Series Fuse Rating

15 A

Material Data

Panel Dimension (H/W/D)

1684x1002x35 mm

Weight

18.5 kg

Cell Size

158×79 mm

Cell Number

120

Glass Type

Tempered

Glass Thickness

3.2 mm

Frame Type

Anodized Aluminium

Cable Crossection

4 mm²

PDF

Download Manufacturer's PDF

Datasheet

Production Line

Certificates

Projects

Ningbo Rarlon Photovoltaic Technology Co., Ltd.

: Click to show company phone
: www.rarlonsolar.com
: China
: Building B, No. 41, Jinghua Road, No. 188, High-Tech Zone, Ningbo, Zhejiang

Contact Manufacturer

Note: Your Enquiry will be sent directly to Ningbo Rarlon Photovoltaic Technology Co., Ltd..

Crystalline

Production (MW)/: MWp

Monocrystalline, Polycrystalline

Power Range(Wp): 100-670

Useful Contacts

Bella Sales

Company Description

Rarlon PV TECH has specialized in solar field more than 10 years. Rarlon Solar is a professional manufacturer and supplier of green energy products. We engage production and installation of solar products, including solar panels, solar systems and solar projects.

At present, Rarlon PV TECH has exported to many countries, mainly focus on Europe, South America, Middle East, Africa, Southeast Asian countries. All of our products are greatly appreciated in a variety of different markets throughout the world. Why choose us? In Rarlon Solar, you can enjoy high quality service, we offer high efficienct solution.

Through solar products, making the world more beautiful and clean is our core goal, we will always work on innovation and do our best for a better world.
