JAM72S20 445-470/MR

JA Solar JAM72S20 445-470/MR

Raylyst Solar s.r.o.
Price:
From €0.240 / Wp
Type: PERC
Power Range: 445 ~ 470 Wp
Region: Czech Republic Czech Republic
Note: Your Enquiry will be sent directly to Raylyst Solar s.r.o..

Description:

IEC 61215, IEC 61730, IEC TS 62804, UL61730, MCS Certificate

ISO 9001: 2015 Quality management systems

ISO 14001: 2015 Environmental management systems

OHSAS 18001: 2007 Occupational health and safety management systems

IEC TS 62941: 2016 Terrestrial photovoltaic (PV) modules – Guidelines for increased confidence in PV module design qualification and type approval

Product Characteristics

Model No.
JAM72S20-445/MR JAM72S20-450/MR JAM72S20-455/MR JAM72S20-460/MR JAM72S20-465/MR JAM72S20-470/MR
Warranty
Product Warranty 12 Years
Power Warranty 15 Years of 90.3% Output Power, 25 Years of 84.8% Output Power
Electrical Data at STC
Maximum Power (Pmax)
445 Wp 450 Wp 455 Wp 460 Wp 465 Wp 470 Wp
Voltage at Maximum Power (Vmpp)
41.21 V 41.52 V 41.82 V 42.13 V 42.43 V 42.69 V
Current at Maximum Power (Impp)
10.8 A 10.84 A 10.88 A 10.92 A 10.96 A 11.01 A
Open Circuit Voltage (Voc)
49.56 V 49.7 V 49.85 V 50.01 V 50.15 V 50.31 V
Short Circuit Current (Isc)
11.32 A 11.36 A 11.41 A 11.45 A 11.49 A 11.53 A
Panel Efficiency
20 % 20.3 % 20.5 % 20.7 % 20.9 % 21.2 %
Power Tolerance (Positive)
+ 1 % + 1 % + 1 % + 1 % + 1 % + 1 %
  Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Maximum Power (Pmax)
336 Wp 340 Wp 344 Wp 348 Wp 352 Wp 355 Wp
Voltage at Maximum Power (Vmpp)
38.95 V 39.19 V 39.44 V 39.68 V 39.9 V 40.1 V
Current at Maximum Power (Impp)
8.64 A 8.68 A 8.72 A 8.76 A 8.81 A 8.86 A
Open Circuit Voltage (Voc)
46.65 V 46.9 V 47.15 V 47.38 V 47.61 V 47.84 V
Short Circuit Current (Isc)
9.2 A 9.25 A 9.29 A 9.33 A 9.38 A 9.42 A
Temperature 45±2 °C
  Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range -40~85 °C
Temperature Coefficient of Pmax -0.35 %/°C
Temperature Coefficient of Voc -0.272 %/°C
Temperature Coefficient of Isc 0.044 %/°C
Maximum Ratings
Maximum System Voltage 1500 V
Series Fuse Rating 20 A
Material Data
Panel Dimension (H/W/D) 2112x1052x35 mm
Weight 24.5 kg
Cell Type PERC
Cell Number 144
Junction Box Diodes 3
Junction Box Protection Class IP 68
Connector Type MC4
Cable Crossection 4 mm2
Cable Length 1200 mm
PDF
Download Manufacturer's PDF

Our Brands

Bloomberg Tier 1 manufacturer JA Solar was founded in 2005. With ranging products from silicon wafers, cells, and modules to complete photovoltaic power systems, its products are sold to 135 countries and regions. On the strength of its continuous technological innovation, sound financial condition, well-established global sales and customer service network, JA Solar has been highly recognized by authoritative associations in the industry as a leading global manufacturer of high-performance PV products
