GPNE-S108/M10H 390-410W

Jiangsu Green Power New Energy Co., Ltd.

Type:	Monocrystalline
Power Range:	390 ~ 410 Wp
Region:	China

Note: Your Enquiry will be sent directly to Jiangsu Green Power New Energy Co., Ltd..

Alternative Product

NEX Series 415...

Sonnex Energie

From €0.500 / Wp

Cell Type: TOPCon
Dimensions: 1722x1134x30 mm
Weight: 25.4 kg
Cell Size: 182x182 mm
Glass Thickness: 2 mm

Product Info
Company Profile

Product Characteristics

Model No.

390

395

400

405

410

Warranty

Product Warranty

12 Years

Power Warranty

25 Years of 84.8% Output Power

Electrical Data at STC

Maximum Power (Pmax)

390 Wp

395 Wp

400 Wp

405 Wp

410 Wp

Voltage at Maximum Power (Vmpp)

30.76 V

30.98 V

31.18 V

31.38 V

31.59 V

Current at Maximum Power (Impp)

12.69 A

12.76 A

12.83 A

12.91 A

12.98 A

Open Circuit Voltage (Voc)

36.62 V

36.84 V

37.04 V

37.24 V

37.45 V

Short Circuit Current (Isc)

13.59 A

13.66 A

13.73 A

13.81 A

13.88 A

Panel Efficiency

19.9 %

20.2 %

20.5 %

20.7 %

21 %

Power Tolerance (Positive)

+ 3 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Maximum Power (Pmax)

294.9 Wp

298.6 Wp

302.3 Wp

306 Wp

309.6 Wp

Voltage at Maximum Power (Vmpp)

28.4 V

28.6 V

28.8 V

29 V

29.2 V

Current at Maximum Power (Impp)

10.38 A

10.44 A

10.5 A

10.56 A

10.62 A

Open Circuit Voltage (Voc)

34.4 V

34.6 V

34.8 V

35 V

35.2 V

Short Circuit Current (Isc)

10.93 A

10.98 A

11.04 A

11.1 A

11.16 A

Temperature

42±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

40~85 °C

Temperature Coefficient of Pmax

0.36 %/°C

Temperature Coefficient of Voc

0.304 %/°C

Temperature Coefficient of Isc

0.05 %/°C

Maximum Ratings

Maximum System Voltage

1500 V

Series Fuse Rating

25 A

Material Data

Panel Dimension (H/W/D)

1724x1134x35 mm

Weight

22.1 kg

Cell Type

Monocrystalline

Cell Size

125×125 mm

Cell Number

108

Glass Type

Anti-reflection Coating

Glass Thickness

3.2 mm

Frame Type

Anodized Aluminium Alloy

Junction Box Protection Class

IP 68

Connector Type

MC4

Cable Crossection

4 mm²

Cable Length

350 mm
