CE-395-415HM Full Black

Centro Energy Co., Ltd.

Type:	Monocrystalline
Power Range:	395 ~ 415 Wp
Region:	China

Note: Your Enquiry will be sent directly to Centro Energy Co., Ltd..

Description:

1. 12 years product warranty, 25 years linear performance warranty

2. 3% - 5% positive tolerance ensures more power is generated

3. Withstand snow loads up to 5400 Pa and wind loads up to 2400 Pa under extreme temperature

4. Certification and approval under CE, TUV, IEC 61215, IEC 61730, ISO9001, ISO14001 and PV CYCLE

Product Info
Company Profile

Product Characteristics

Model No.

CE-395HM

CE-400HM

CE-405HM

CE-410HM

CE-415HM

Warranty

Product Warranty

12 Years

Power Warranty

12 Years of 90% Output Power, 25 Years of 80% Output Power

Electrical Data at STC

Maximum Power (Pmax)

395 Wp

400 Wp

405 Wp

410 Wp

415 Wp

Voltage at Maximum Power (Vmpp)

30.84 V

31.01 V

31.21 V

31.45 V

31.61 V

Current at Maximum Power (Impp)

12.81 A

12.9 A

12.98 A

13.04 A

13.13 A

Open Circuit Voltage (Voc)

36.98 V

37.07 V

37.23 V

37.32 V

37.45 V

Short Circuit Current (Isc)

13.7 A

13.79 A

13.87 A

13.95 A

14.02 A

Panel Efficiency

20.22 %

20.48 %

20.74 %

21 %

21.25 %

Power Tolerance (Positive)

+ 1 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Temperature

45±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Temperature Coefficient of Pmax

-0.35 %/°C

Temperature Coefficient of Voc

-0.275 %/°C

Temperature Coefficient of Isc

0.045 %/°C

Maximum Ratings

Maximum System Voltage

1500 V

Series Fuse Rating

25 A

Material Data

Panel Dimension (H/W/D)

1722x1134x30 mm

Weight

21.5 kg

Cell Type

Monocrystalline

Cell Number

108

Glass Type

Tempered

Glass Thickness

3.2 mm

Frame Type

Anodized Aluminium Alloy

Junction Box Diodes

Junction Box Protection Class

IP 68

Connector Type

MC4

Cable Crossection

4 mm²

Cable Length

900 mm

PDF

Download Manufacturer's PDF

Product Features

High conversion efficiency through advanced manufacturing technology

12 years product warranty, 25 years linear performance warranty

3% - 5% positive tolerance ensures more power is generated

Withstand snow loads up to 5400Pa and wind loads up to 2400Pa under extreme temperature

Anti-PID modules effectively reduce the loss in solar panel power output

Anti-salt mist corrosion & anti-ammonia corrosion tested

Certificates

Manufactured according to International Management System Standard

Quality Management system: ISO9001

Environmental Management System: ISO14001

Occupational Health and Safety Management System: OHSAS18001

Certified and approved by CE, TUV, IEC 61215, IEC 61730, MCS, CEC and PV CYCLE

About Centro Energy

Centro Energy is a cell-to-module manufacturing facility employing state-of-the-art robotic equipment located in China and Vietnam, as well as an international photovoltaic system integrator.

For Manufacturing, we have 200MW solar cells and 300MW solar modules in China, 300MW solar module capacity in Vietnam. Our professional team has over 8 years industry experience in manufacturing, quality controlling, and logistics services. Full rangers of Centro Energy’s solar modules are produced in accordance with international standard of IEC61215 and IEC61730.

Centro Energy continuously delivers high quality solar cells and modules to customers worldwide, and products are widely used for homes, factories and public facilities in more than 40 countries such as Germany, Netherland, Japan, Thailand, Australia, Chile, Russia, etc.

Currently Centro Energy could provide customers with mono and poly crystalline solar cells, standard solar modules, black solar modules, smart modules as well as customized products like OEM and ODM. Meanwhile, we invest more in R&D advancing our technology to rapidly increase our energy efficiency and provide stable quality.

For projects, we have developed, financed, engineered, constructed and currently operates many grid-connected PV power plants. Our experience across the solar value chain reduces risk while delivering more reliable, dependable and cost-effective products and solutions for our customers.

What we do

• Continuously improving cell efficiency

• Strict quality control

• Customer satisfaction by better yield, reliability and performance of product

• Ensuring timely delivery to customers

• In-house reliability testing capability to ensure high quality product

• State of the art manufacturing facility with cutting-edge technology

• Develop, plan, build and operate residential solar system, commercial and industrial solar plants
