PIX MP3 72 370-400W

Pixon Green Energy Private Limited

Type:	PERC
Power Range:	370 ~ 400 Wp
Region:	India

Note: Your Enquiry will be sent directly to Pixon Green Energy Private Limited.

Description:

PID Resistance with long-term reliability

Better performance even at low irradiation

Maximum System Voltage - 1500V DC

Increased string length & low BOS cost

Withstand up to 5400Pa of snow load and up to 2400Pa of wind load

Rigorous Testing Criteria - 100% EL inspection ensuring defect-free modules

Product Info
Company Profile

Product Characteristics

Model No.

PIX MP3 72 370

PIX MP3 72 375

PIX MP3 72 380

PIX MP3 72 385

PIX MP3 72 390

PIX MP3 72 395

PIX MP3 72 400

Warranty

Product Warranty

10 Years

Power Warranty

10 Years of 92.1% Output Power, 25 Years of 84.39% Output Power

Electrical Data at STC

Maximum Power (Pmax)

370 Wp

375 Wp

380 Wp

385 Wp

390 Wp

395 Wp

400 Wp

Voltage at Maximum Power (Vmpp)

40.25 V

40.31 V

40.61 V

40.82 V

41.04 V

41.33 V

41.69 V

Current at Maximum Power (Impp)

9.2 A

9.31 A

9.36 A

9.44 A

9.51 A

9.56 A

9.6 A

Open Circuit Voltage (Voc)

47.16 V

47.38 V

47.52 V

47.74 V

47.95 V

48.17 V

48.53 V

Short Circuit Current (Isc)

10.15 A

10.18 A

10.25 A

10.27 A

10.32 A

10.36 A

10.4 A

Panel Efficiency

18.64 %

18.89 %

19.14 %

19.4 %

19.65 %

19.9 %

20.15 %

Power Tolerance (Positive)

+ 1.5 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Maximum Power (Pmax)

274.45 Wp

278.15 Wp

281.72 Wp

285.6 Wp

289.27 Wp

292.84 Wp

296.63 Wp

Voltage at Maximum Power (Vmpp)

37.76 V

37.82 V

38.1 V

38.3 V

38.5 V

38.78 V

39.11 V

Current at Maximum Power (Impp)

7.27 A

7.35 A

7.39 A

7.46 A

7.51 A

7.55 A

7.58 A

Open Circuit Voltage (Voc)

44.25 V

44.45 V

44.58 V

44.79 V

44.99 V

45.19 V

45.53 V

Short Circuit Current (Isc)

8.22 A

8.25 A

8.3 A

8.32 A

8.36 A

8.39 A

8.42 A

Temperature

45±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

40~85 °C

Temperature Coefficient of Pmax

0.4080 %/°C

Temperature Coefficient of Voc

0.3090 %/°C

Temperature Coefficient of Isc

0.0626 %/°C

Maximum Ratings

Maximum System Voltage

1500 V

Series Fuse Rating

20 A

Material Data

Panel Dimension (H/W/D)

1985x1000x35 mm

Weight

22 kg

Cell Type

PERC

Cell Number

Glass Type

Anti-reflection Coating, Tempered

Glass Thickness

3.2 mm

Encapsulant Type

EVA

Frame Type

Anodized Aluminium Alloy

Junction Box Diodes

Junction Box Protection Class

IP 68

Connector Type

MC4

Cable Crossection

4 mm²

Cable Length

1200 mm

PDF

Download Manufacturer's PDF
