PEX Series 400-410W Dual Glass Solar Module

Name: PEX Series 400-410W Dual Glass Solar Module
Brand: Sonnex Energie
SKU: 53691
Price: 0.48000 EUR
Availability: InStock

Sonnex Energie GmbH

Price:

From €0.480 / Wp

Type:	Bifacial
Power Range:	390 ~ 410 Wp
Region:	Germany

Note: Your Enquiry will be sent directly to Sonnex Energie GmbH.

Description:

IEC61215，61730 certified

Lower hot spot risks

Lower Pmax temperature coefficient

Lower LCOE for shorter payback period

Excellent anti-PID performance

Mechanical loading 5400Pa and Wind loading 2400Pa

Up to 20 years product warranty terms and 30 years power warranty

Product Info
Company Profile

Product Characteristics

Model No.

SNX-D54HPD-390M

SNX-D54HPD-395M

SNX-D54HPD-400M

SNX-D54HPD-405M

SNX-D54HPD-410M

Warranty

Product Warranty

30 Years

Power Warranty

30 Years of 82.05% Output Power

Electrical Data at STC

Maximum Power (Pmax)

390 Wp

395 Wp

400 Wp

405 Wp

410 Wp

Voltage at Maximum Power (Vmpp)

31.23 V

31.3 V

31.38 V

31.45 V

31.52 V

Current at Maximum Power (Impp)

12.49 A

12.62 A

12.75 A

12.88 A

13.01 A

Open Circuit Voltage (Voc)

36.69 V

37.04 V

37.13 V

37.21 V

37.29 V

Short Circuit Current (Isc)

13.24 A

13.47 A

13.6 A

13.73 A

13.86 A

Panel Efficiency

19.97 %

20.23 %

20.48 %

20.74 %

21 %

Power Tolerance (Positive)

+ 1 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Temperature

45±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

40~85 °C

Temperature Coefficient of Pmax

0.35 %/°C

Temperature Coefficient of Voc

0.2 %/°C

Temperature Coefficient of Isc

0.05 %/°C

Maximum Ratings

Maximum System Voltage

1500 V

Series Fuse Rating

25 A

Material Data

Panel Dimension (H/W/D)

1722x1134x30 mm

Weight

25.4 kg

Cell Type

Bifacial

Cell Number

108

Glass Type

Anti-reflection Coating, Tempered

Glass Thickness

2 mm

Frame Type

Anodized Aluminium Alloy

Junction Box Protection Class

IP 68

Connector Type

MC4

Cable Crossection

4 mm²

Cable Length

300 mm

PDF

Download Manufacturer's PDF

About Us

Sonnex is focusing on solar module development and manufacturing with more than 2GW annual capacity, which is equipped with highly automatic production lines. With its headquarters in Germany, Sonnex stands for products that meet the highest quality standards of tomorrow. We only use the most recent cell technologies and go for a sublime finish. Thanks to this approach, Sonnex offers extremely reliable modules with strong market performance.

At Sonnex we have designed our product range in such a way that you will find a solution for every installation or project. We distinguish ourselves from other brands by our focus on quality, aesthetics, and sustainability.

Sonnex product types include PERC half-cell modules (405~605W) and shingled cell modules (390~650W), and higher efficiency N-type TOPCon (415W~580W) and IBC modules (390~430W) with the highest module efficiency above 22%. Bifacial dual-glass modules and all-black solar modules are available for different project applications.

Sonnex Energie offers up to 20 years product warranty and 30 years power warranty.
