N-TopCon Solar Panel Mono 585W-615W Monofacial

Name: N-TopCon Solar Panel Mono 585W-615W Monofacial
Brand: Ocean Solar
SKU: 55785
Price: 0.07165 USD
Availability: InStock

Jiangsu Ocean Solar Co., Ltd.

Price:

From €0.062 / Wp

Price per Piece
Minimum Order	740-2999 Pieces	3000-6999 Pieces	7000+ Pieces
Lead Time	21 Days	21 Days	21 Days
AOX-72M10HC590W	€38.5	€37.4	€36.6

Technology:	TOPCon, N-type
Power Range:	580 ~ 615 Wp
Region:	China

Contact Manufacturer

Note: Your Enquiry will be sent directly to Jiangsu Ocean Solar Co., Ltd..

Description:

Based on M10-182mm solar cells
Higher module quality ensures long-term reliability
MBB technology enhances light trapping and current collection for improved module power and reliability
Excellent Anti-PID performance guarantee via optimized mass production process and materials control

Product Info
Company Profile

Product Characteristics

Type

Monocrystalline

Model No.

AOX-72M10HC580W

AOX-72M10HC585W

AOX-72M10HC590W

AOX-72M10HC595W

AOX-72M10HC600W

AOX-72M10HC605W

AOX-72M10HC610W

AOX-72M10HC615W

Warranty

Product Warranty

12 Years

Power Warranty

12 Years of 90% Output Power, 30 Years of 80% Output Power

Electrical Data at STC

Maximum Power (Pmax)

580 Wp

585 Wp

590 Wp

595 Wp

600 Wp

605 Wp

610 Wp

615 Wp

Voltage at Maximum Power (Vmpp)

43.5 V

43.7 V

43.9 V

44.1 V

44.3 V

44.5 V

44.7 V

44.9 V

Current at Maximum Power (Impp)

13.34 A

13.37 A

13.44 A

13.5 A

13.55 A

13.6 A

13.65 A

13.7 A

Open Circuit Voltage (Voc)

50.5 V

50.7 V

50.9 V

51.1 V

51.3 V

51.5 V

51.7 V

51.9 V

Short Circuit Current (Isc)

14.08 A

14.14 A

14.19 A

14.25 A

14.3 A

14.35 A

14.41 A

14.46 A

Panel Efficiency

22.4 %

22.6 %

22.8 %

23 %

23.2 %

23.4 %

23.6 %

23.8 %

Power Tolerance (Positive)

+ 3 %

Power Tolerance (Negative)

- 3 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Maximum Power (Pmax)

438 Wp

442 Wp

446 Wp

450 Wp

454 Wp

458 Wp

462 Wp

466 Wp

Voltage at Maximum Power (Vmpp)

40.7 V

40.9 V

41.1 V

41.3 V

41.5 V

41.7 V

41.9 V

42.1 V

Current at Maximum Power (Impp)

10.76 A

10.81 A

10.86 A

10.9 A

10.94 A

10.99 A

11.03 A

11.07 A

Open Circuit Voltage (Voc)

47.7 V

47.9 V

48.1 V

48.3 V

48.5 V

48.7 V

48.9 V

49.1 V

Short Circuit Current (Isc)

11.36 A

11.41 A

11.46 A

11.51 A

11.55 A

11.6 A

11.64 A

11.68 A

Temperature

45±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

-40~+85 °C

Temperature Coefficient of Pmax

-0.30 %/°C

Temperature Coefficient of Voc

-0.24 %/°C

Temperature Coefficient of Isc

0.04 %/°C

Maximum Ratings

Maximum System Voltage

1500 V

Series Fuse Rating

30 A

Material Data

Panel Dimension (H/W/D)

2278x1134x30 mm

Weight

28 kg

Cell Size

182×91 mm

Cell Number

144

Glass Type

Anti-reflection Coating, Tempered

Glass Thickness

3.2 mm

Encapsulant Type

EVA

Back Cover Type

TPT

Frame Type

Aluminium

Junction Box Diodes

Junction Box Protection Class

IP 68

Connector Type

MC4

Cable Crossection

4 mm²

Cable Length

300 mm

PDF

Download Manufacturer's PDF

Specification
