LF670M12-66H

Ningbo Lefeng New Energy Co., Ltd

Price:

From €0.127 / Wp

Type:	Monocrystalline
Power Range:	650 ~ 670 Wp
Region:	China

Note: Your Enquiry will be sent directly to Ningbo Lefeng New Energy Co., Ltd.

Description:

Thanks to half-cell technology, the module produces higher power output and effectively reduces the system cost

Good performance in terms of reducing shading losses and low internal resistance losses

The half-cell technology helps to effectively alleviate the hot spot risk in high-power modules

Better power generation performance and reliability when used in PV systems

Product Info
Company Profile

Product Characteristics

Model No.

LF650M12-66H

LF655M12-66H

LF660M12-66H

LF665M12-66H

LF670M12-66H

Warranty

Product Warranty

12 Years

Electrical Data at STC

Maximum Power (Pmax)

650 Wp

655 Wp

660 Wp

665 Wp

670 Wp

Voltage at Maximum Power (Vmpp)

37.75 V

37.91 V

38.08 V

38.28 V

38.43 V

Current at Maximum Power (Impp)

17.23 A

17.28 A

17.33 A

17.37 A

17.43 A

Open Circuit Voltage (Voc)

45.68 V

45.87 V

46.03 V

46.24 V

46.42 V

Short Circuit Current (Isc)

18.35 A

18.4 A

18.46 A

18.5 A

18.56 A

Panel Efficiency

20.92 %

21.41 %

21.25 %

21.41 %

21.57 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Maximum Power (Pmax)

499.35 Wp

503.19 Wp

507.03 Wp

510.87 Wp

514.71 Wp

Voltage at Maximum Power (Vmpp)

34.41 V

34.56 V

34.71 V

34.89 V

35.03 V

Current at Maximum Power (Impp)

14.51 A

14.56 A

14.61 A

14.65 A

14.69 A

Open Circuit Voltage (Voc)

42.17 V

42.35 V

42.5 V

42.69 V

42.86 V

Short Circuit Current (Isc)

15.6 A

15.65 A

15.7 A

15.75 A

15.79 A

Temperature

45±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

-40~85 °C

Temperature Coefficient of Pmax

-0.354 %/°C

Temperature Coefficient of Voc

-0.266 %/°C

Temperature Coefficient of Isc

0.046 %/°C

Maximum Ratings

Maximum System Voltage

1500 V

Series Fuse Rating

30 A

Material Data

Panel Dimension (H/W/D)

2384x1303x35 mm

Weight

34 kg

Cell Type

Monocrystalline

Cell Number

Glass Thickness

3.2 mm

Junction Box Diodes

Junction Box Protection Class

IP 68

Connector Type

MC4

Cable Crossection

4 mm²

Cable Length

300 mm
