JMPV-T7/66-705-715(R)

Name: JMPV-T7/66-705-715(R)
Brand: Solargiga Energy
SKU: 56249
Price: 0.26600 USD
Availability: InStock

Solargiga Energy Holdings Ltd.

Price:

From €0.247 / Wp

Type:	HJT, Bifacial
Power Range:	705 ~ 715 Wp
Region:	China

Note: Your Enquiry will be sent directly to Solargiga Energy Holdings Ltd..

Description:

An astounding output of 715W and an efficiency of 23%
Several technologies including bifacial, N-type, heterojunction, 12-busbar, and half-cell architecture
High PID resistance and durable components
Can withstand wind or snow pressure of up to 5400Pa on the front side and 2400Pa on the rear
Warranty - 12/25 years

Product Info
Company Profile

Product Characteristics

Model No.

705

710

715

Warranty

Product Warranty

12 Years

Power Warranty

25 Years of 84.8% Output Power

Electrical Data at STC

Maximum Power (Pmax)

705 Wp

710 Wp

715 Wp

Voltage at Maximum Power (Vmpp)

39.08 V

39.23 V

39.36 V

Current at Maximum Power (Impp)

18.04 A

18.1 A

18.17 A

Open Circuit Voltage (Voc)

46.91 V

47.08 V

47.24 V

Short Circuit Current (Isc)

19.12 A

19.18 A

19.25 A

Panel Efficiency

22.7 %

22.86 %

23.02 %

Power Tolerance (Positive)

+ 1 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Maximum Power (Pmax)

528.59 Wp

532.45 Wp

536.4 Wp

Voltage at Maximum Power (Vmpp)

36.43 V

36.57 V

36.69 V

Current at Maximum Power (Impp)

14.51 A

14.56 A

14.62 A

Open Circuit Voltage (Voc)

44.46 V

44.62 V

44.77 V

Short Circuit Current (Isc)

15.5 A

15.55 A

15.61 A

Temperature

42.5±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

-40~85 °C

Temperature Coefficient of Pmax

-0.25 %/°C

Temperature Coefficient of Voc

-0.24 %/°C

Temperature Coefficient of Isc

0.046 %/°C

Maximum Ratings

Maximum System Voltage

1500 V

Series Fuse Rating

30 A

Material Data

Panel Dimension (H/W/D)

2384x1303x35 mm

Weight

33.4 kg

Cell Type

HJT, Bifacial

Cell Number

132

Glass Type

Tempered

Glass Thickness

3.2 mm

Encapsulant Type

EVA

Junction Box Protection Class

IP 68

Cable Crossection

4 mm²

PDF

Download Manufacturer's PDF
