Obsidian TPS-108-CELL

Name: Obsidian TPS-108-CELL
Brand: Topsola
SKU: 56897
Price: 0.25500 USD
Availability: InStock

Topsola Green Energy Technology Co., Ltd

Price:

From €0.241 / Wp

Type:	Monocrystalline
Power Range:	400 ~ 420 Wp
Region:	China

Note: Your Enquiry will be sent directly to Topsola Green Energy Technology Co., Ltd.

Description:

Power range of 420 Wp and an efficiency of 21.5%
Low-temperature coefficient of -0.345%/°C
Robust design with an IP68 junction box, 2 mm front and back glass, and an anodized aluminium frame
Can withstand a max front static load of 5400 Pa and back static load of 2400 Pa
Certified by IEC 61215, IEC 61730, CE, MCS

Product Info
Company Profile

Product Characteristics

Model No.

395

Electrical Data at STC

Maximum Power (Pmax)

395 Wp

Voltage at Maximum Power (Vmpp)

30.84 V

Current at Maximum Power (Impp)

12.81 A

Open Circuit Voltage (Voc)

36.98 V

Short Circuit Current (Isc)

13.7 A

Panel Efficiency

20.2 %

Power Tolerance (Positive)

+ 1 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

Electrical Data at NOCT

Temperature

45±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

-40~85 °C

Temperature Coefficient of Pmax

-0.345 %/°C

Temperature Coefficient of Voc

-0.263 %/°C

Temperature Coefficient of Isc

0.049 %/°C

Maximum Ratings

Maximum System Voltage

1500 V

Series Fuse Rating

25 A

Material Data

Panel Dimension (H/W/D)

1722x1134x30 mm

Weight

25 kg

Cell Type

Monocrystalline

Cell Number

108

Glass Thickness

2 mm

Frame Type

Anodized Aluminium Alloy

Junction Box Protection Class

IP 68

Cable Crossection

4 mm²

Cable Length

300 mm

PDF

Download Manufacturer's PDF

Topsola Green Energy Technology Co., Ltd

: Click to show company phone
: www.topsola.com
: China
: No. 7, Qilin Avenue, Xuanzhou District, Xuancheng, Anhui

Note: Your Enquiry will be sent directly to Topsola Green Energy Technology Co., Ltd.

Crystalline

Production (MW)/: MWp

Monocrystalline, Polycrystalline

Power Range(Wp): 375-670

Useful Contacts

Harlem Zheng

Edward He Sales Support

Lotte Saler

Company Description

Hongrun Topsola Green Energy Co., Ltd.

Topsola was founded in 2002, relying on the technical strength of Shanghai Jiao Tong University in the photovoltaic industry, Topsola become a well-known brand in the global solar market with its leading technical advantages and product quality. In 2005, Topsola products passed IEC61215 and IEC61730 tests and successfully developed international and domestic markets with a variety of sales and reliable quality.

Topsola is a subsidiary of Hongrun Construction Group Co., LTD. Hongrun Construction Group founded in 1973, is a China top 500 listed enterprise focused on construction and infrastructure investment, renewable energy development, finance, education, etc.

Topsola invests in its own industrial park in China to build up 10GW high-efficiency module smart factory and 10GW photovoltaic cell project, for which the total investment is over 15 billion USD.
