MS-M966H 640-660W

MS-M966H 640-660W

Maysun Solar Co., Ltd
Price:
From €0.110 / Wp
Type: Monocrystalline
Power Range: 640 ~ 660 Wp
Region: China China
Contact Manufacturer
Note: Your Enquiry will be sent directly to Maysun Solar Co., Ltd.

Alternative Product

RL530HM-550HM

Rarlon PV Tech
From €0.111 / Wp
  • Cell Type: Monocrystalline
  • Dimensions: 2279x1134x35 mm
  • Weight: 27 kg
  • Cell Size: --
  • Glass Thickness: 3.2 mm

Product Characteristics

Model No.
MS-M966H 640W MS-M966H 645W MS-M966H 650W MS-M966H 655W MS-M966H 660W
Warranty
Product Warranty 12 Years
Power Warranty 10 Years of 90% Output Power, 25 Years of 80% Output Power
Electrical Data at STC
Maximum Power (Pmax)
640 Wp 645 Wp 650 Wp 655 Wp 660 Wp
Voltage at Maximum Power (Vmpp)
37.5 V 37.7 V 37.91 V 38.11 V 38.29 V
Current at Maximum Power (Impp)
17.07 A 17.11 A 17.15 A 17.19 A 17.24 A
Open Circuit Voltage (Voc)
44.6 V 44.8 V 45 V 45.21 V 45.39 V
Short Circuit Current (Isc)
18.31 A 18.35 A 18.38 A 18.44 A 18.47 A
Panel Efficiency
20.61 % 20.77 % 20.93 % 21.09 % 21.25 %
Power Tolerance (Positive)
+ 3 % + 3 % + 3 % + 3 % + 3 %
  Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Maximum Power (Pmax)
475 Wp 479 Wp 483 Wp 487 Wp 491 Wp
Voltage at Maximum Power (Vmpp)
34.35 V 34.51 V 34.67 V 34.83 V 35.01 V
Current at Maximum Power (Impp)
13.84 A 13.89 A 13.94 A 13.99 A 14.02 A
Open Circuit Voltage (Voc)
41.45 V 41.64 V 41.83 V 42.02 V 42.19 V
Short Circuit Current (Isc)
14.77 A 14.81 A 14.85 A 14.89 A 14.92 A
Temperature 45±2 °C
  Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range -40~85 °C
Temperature Coefficient of Pmax -0.34 %/°C
Temperature Coefficient of Voc -0.25 %/°C
Temperature Coefficient of Isc 0.04 %/°C
Maximum Ratings
Maximum System Voltage 1500 V
Series Fuse Rating 30 A
Material Data
Panel Dimension (H/W/D) 2384x1303x35 mm
Weight 34.4 kg
Cell Type Monocrystalline
Cell Size 210×210 mm
Cell Number 132
Glass Type Tempered
Glass Thickness 3.2 mm
Encapsulant Type EVA
Back Cover Type TPT
Frame Type Anodized Aluminium
Junction Box Diodes 3
Junction Box Protection Class IP 68
Connector Type MC4
Cable Crossection 4 mm2
Cable Length 300 mm
PDF
Download Manufacturer's PDF

Maysun Solar Co., Ltd

Click to show company phone
www.maysunpv.com
China
No. 118, Huyan West Road, Lianshi Town, Nanxun District, Huzhou City, Zhejiang Province
Note: Your Enquiry will be sent directly to Maysun Solar Co., Ltd.

Crystalline

Production (MW)/: MWp
Monocrystalline, Polycrystalline
Power Range(Wp): 160-660
