Price per Piece
|
|||
Minimum Order | 1-99 Pieces | 100-999 Pieces | 1000+ Pieces |
HS640-MHG-D | €55.7 | €55.0 | €54.4 |
HS645-MHG-D | €56.1 | €55.5 | €54.8 |
HS650-MHG-D | €56.6 | €55.9 | €55.3 |
HS655-MHG-D | €57.0 | €56.3 | €55.7 |
HS660-MHG-D | €57.4 | €56.8 | €56.1 |
HS665-MHG-D | €57.9 | €57.2 | €56.5 |
Technology: | Bifacial |
---|---|
Power Range: | 640 ~ 665 Wp |
Region: |
China
![]() |
Type | Monocrystalline | ||||||
---|---|---|---|---|---|---|---|
Model No. |
|
||||||
Warranty | |||||||
Product Warranty | 15 Years | ||||||
Electrical Data at STC | |||||||
Maximum Power (Pmax) |
|
||||||
Voltage at Maximum Power (Vmpp) |
|
||||||
Current at Maximum Power (Impp) |
|
||||||
Open Circuit Voltage (Voc) |
|
||||||
Short Circuit Current (Isc) |
|
||||||
Panel Efficiency |
|
||||||
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C | |||||||
Electrical Data at NOCT | |||||||
Maximum Power (Pmax) |
|
||||||
Voltage at Maximum Power (Vmpp) |
|
||||||
Current at Maximum Power (Impp) |
|
||||||
Open Circuit Voltage (Voc) |
|
||||||
Short Circuit Current (Isc) |
|
||||||
Temperature | 45±2 °C | ||||||
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C | |||||||
Thermal Ratings | |||||||
Operating Temperature Range | -40~85 °C | ||||||
Temperature Coefficient of Pmax | -0.34 %/°C | ||||||
Temperature Coefficient of Voc | -0.28 %/°C | ||||||
Temperature Coefficient of Isc | 0.05 %/°C | ||||||
Maximum Ratings | |||||||
Maximum System Voltage | 1500 V | ||||||
Series Fuse Rating | 30 A | ||||||
Material Data | |||||||
Panel Dimension (H/W/D) | 2384x1303x35 mm | ||||||
Weight | 32.5 kg | ||||||
Cell Size | 210×105 mm | ||||||
Cell Number | 132 | ||||||
Frame Type | Aluminium, Black | ||||||
Junction Box Protection Class | IP 68 | ||||||
Connector Type | MC4 | ||||||
Cable Crossection | 4 mm2 | ||||||
Cable Length | 1300 mm | ||||||
Download Manufacturer's PDF |
