TP6/8KTL

TP6/8KTL

Thinkpower New Energy (Wuxi) Co., Ltd.
Type: On-Grid
Power Range: --
Region: China China
Contact Manufacturer
Product is no longer manufactured.
BDM-800
Solar Inverter
NEP - BDM-800
From €0.0965 / Wp
MARS-5-14G2-LE
Solar Inverter
Chisage ESS - MARS-5-14G2-LE
From €0.109 / Wp

Product Characteristics

Model No.
TP6KTL(5KW) TP6KTL TP8KTL
Warranty
Product Warranty (Min)
5 Years 5 Years 5 Years
Input Data(DC)
Max. DC Power
5.5 kW 7.5 kW 9.5 kW
Max. DC Voltage
1000 V 1000 V 1000 V
Max. DC Current
34 A 34 A 34 A
MPP(T) Voltage Range
250~850 V 250~850 V 250~850 V
No of MPP Trackers
2 2 2
DC Inputs
1 1 2
Output Data (AC)
Max. AC Power
5.5 kW 7 kW 8.8 kW
Nominal AC Power
5 kW 6 kW 8 kW
Output AC Voltage Range
280~490 V 280~490 V 280~490 V
Nominal AC Voltage
400 V 400 V 400 V
Max. AC Current
10 A 12 A 15 A
Frequency Range
45-55 Hz 45-55 Hz 45-55 Hz
Frequency
50, 60 Hz 50, 60 Hz 50, 60 Hz
Power Factor (cosθ)
0.8 0.8 0.8
Distortion (THD)
< 1.5 % < 1.5 % < 1.5 %
No of feed-in phases
3 3 3
Max. Efficiency
98.2 % 98.2 % 98.2 %
Euro Efficiency
97.7 % 97.7 % 97.7 %
General Data
Dimensions (H/W/D)
400x480x180 mm 400x480x180 mm 400x480x180 mm
Weight
22 kg 22 kg 22 kg
Operating Temperature -25 ~ +60 ℃
Transformer Transformerless
Protection Class IP65
Humidity 0-95 %
Cooling Natural
Interface RS 485, WLAN
Display LCD
Protection Features
Protection Features Residual Current Device (RCD), Reverse Polarity Protection

Thinkpower New Energy (Wuxi) Co., Ltd.

Click to show company phone
https://www.thinkpower.com.cn
China
No.57, ZhongBang MOHO, Binhu district, Wuxi, Jiangsu province, PR. China
Contact Manufacturer
Product is no longer manufactured.

Useful Contacts

Contact Face
Maggie Huang Sales Director
Contact Face
Agnes GU Key Account Director
Contact Face
Andy Ou Overseas Director
Contact Face
Snowy Zhou Key Account Manager
Contact Face
Vivian Xu Key Account Manager
Contact Face
Sara Zhu Key Account Manager
Contact Face
Leo Li Marketing director co-fo...
Contact Face
Dory Overseas Sales Manager
Company Description

Founded in 2011, Thinkpower New Energy (Wuxi) Co., Ltd. is an innovative High-tech manufacturer, specialized in R&D, manufacturing, marketing for renewable energy related products like hybrid energy storage inverter 3-12kW, solar grid tie inverter 1-25kW.

Combined with US technology and Chinese top quality control process, more than 14 years experience in R&D, production and sales, our products reach the balance of quality and price.

Thinkpower boasts of an "old" tech and engineering team with electronic and research experience over 15 years, they used to work in Eaton group, a mature team. We can focus on improvement for the inverter’s function like efficiency, stability and extend product lifetime, then let our product smarter in the 5G world.
