White 380-400W
White 380-400W

White 380-400W

Meyer Burger Technology AG
Type: HJT, Monocrystalline
Power Range: 380 ~ 400 Wp
Region: Switzerland Switzerland
Contact Manufacturer
Note: Your Enquiry will be sent directly to Meyer Burger Technology AG.

Alternative Product

PNG-132M 640-675W

PNG Solar
From €0.112 / Wp
  • Cell Type: Bifacial, PERC
  • Dimensions: 2384x1303x35 mm
  • Weight: 34 kg
  • Cell Size: 210×210 mm
  • Glass Thickness: 3.2 mm
More

Product Characteristics

Model No.
380W 385W 390W 395W 400W
Warranty
Product Warranty 25 Years
Power Warranty 25 Years of 92% Output Power
Electrical Data at STC
Maximum Power (Pmax)
380 Wp 385 Wp 390 Wp 395 Wp 400 Wp
Voltage at Maximum Power (Vmpp)
37.3 V 37.6 V 37.9 V 38.3 V 38.6 V
Current at Maximum Power (Impp)
10.2 A 10.2 A 10.3 A 10.3 A 10.4 A
Open Circuit Voltage (Voc)
44.4 V 44.4 V 44.5 V 44.5 V 44.6 V
Short Circuit Current (Isc)
10.8 A 10.8 A 10.8 A 10.9 A 10.9 A
Panel Efficiency
20.7 % 20.9 % 21.2 % 21.5 % 21.7 %
Power Tolerance (Positive)
+ 1 % + 1 % + 1 % + 1 % + 1 %
  Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Maximum Power (Pmax)
287 Wp 290 Wp 294 Wp 298 Wp 302 Wp
Voltage at Maximum Power (Vmpp)
35.5 V 35.5 V 35.9 V 36.2 V 36.5 V
Current at Maximum Power (Impp)
8.1 A 8.2 A 8.2 A 8.2 A 8.3 A
Open Circuit Voltage (Voc)
42.1 V 42.1 V 42.2 V 42.3 V 42.3 V
Short Circuit Current (Isc)
8.7 A 8.7 A 8.7 A 8.7 A 8.7 A
Temperature 44±2 °C
  Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range -40~85 °C
Temperature Coefficient of Pmax -0.259 %/°C
Temperature Coefficient of Voc -0.234 %/°C
Temperature Coefficient of Isc 0.033 %/°C
Maximum Ratings
Maximum System Voltage 1000 V
Series Fuse Rating 20 A
Material Data
Panel Dimension (H/W/D) 1767x1041x35 mm
Weight 19.7 kg
Cell Type HJT, Monocrystalline
Cell Number 120
Glass Type Anti-reflection Coating, Tempered
Glass Thickness 3.2 mm
Frame Type Anodized Aluminium
Junction Box Diodes 3
Junction Box Protection Class IP 68
Connector Type MC4
Cable Crossection 4 mm2
Cable Length 1200 mm
PDF
Download Manufacturer's PDF
