G12-56.7P 400-420 Single/Double-glass

G12-56.7P 400-420 Single/Double-glass

TCL Photovoltaic Technology Co., Ltd.
Type: Monocrystalline
Power Range: 400 ~ 420 Wp
Region: China China
Contact Manufacturer
Note: Your Enquiry will be sent directly to TCL Photovoltaic Technology Co., Ltd..

Alternative Product

QSUN-M210-132S 650-665W

Q-SUNSolar
From €0.101 / Wp
  • Cell Type: Monocrystalline
  • Dimensions: 2384x1303x35 mm
  • Weight: 35.7 kg
  • Cell Size: 210×210 mm
  • Glass Thickness: 3.2 mm
More

Product Characteristics

Model No.
400 405 410 415 420
Electrical Data at STC
Maximum Power (Pmax)
400 Wp 405 Wp 410 Wp 415 Wp 420 Wp
Voltage at Maximum Power (Vmpp)
29.2 V 29.5 V 29.8 V 30.1 V 30.4 V
Current at Maximum Power (Impp)
13.72 A 13.75 A 13.78 A 13.81 A 13.84 A
Open Circuit Voltage (Voc)
35.4 V 35.6 V 35.8 V 36 V 36.2 V
Short Circuit Current (Isc)
14.6 A 14.63 A 14.66 A 14.69 A 14.72 A
Panel Efficiency
20.4 % 20.6 % 20.9 % 21.1 % 21.4 %
Power Tolerance (Positive)
+ 1 % + 1 % + 1 % + 1 % + 1 %
  Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Temperature 43±2 °C
  Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range -40~85 °C
Temperature Coefficient of Pmax -0.34 %/°C
Temperature Coefficient of Voc -0.27 %/°C
Temperature Coefficient of Isc 0.04 %/°C
Material Data
Panel Dimension (H/W/D) 1808x1086x30 mm
Weight 21 kg
Cell Type Monocrystalline
Cell Number 260
Glass Type Tempered
Glass Thickness 3.2 mm
Frame Type Anodized Aluminium
Junction Box Diodes 3
Junction Box Protection Class IP 68
Cable Crossection 4 mm2
